Electronic Hot Melt Glue Stick
Model TH-703, Electronic Hot Melt Glue Stick is a pure-white adhesive that secures PCBs, wire tacks and housings in seconds while forming a dust- and splash-proof seal. Its 110 °C softening point stays rigid inside appliances operating up to 75 °C, so bonds will not creep under transformer heat or motor vibration. Made from hydrogenated resins and food-grade EVA, the ultra-low-VOC formula helps factories pass REACH, RoHS and indoor-air audits without extra ventilation.
Description
Key features
Electronic Hot Melt Glue Stick was developed specifically for white-goods, power-tool, LED-driver and small-appliance manufacturers that need rapid, clean assembly combined with long-term environmental protection. The adhesive extrudes smoothly at 150-170 °C through 11 mm glue guns or micro-dispensing heads, wetting ABS, PC, PP, aluminum and copper without corrosion or bloom. Within 3-6 seconds the bond cools to a tough, white, non-yellowing thermoplastic that delivers 3.5 MPa shear strength on ABS/ABS joints and passes 1000 h at 70 °C/85 % RH without weight loss or cracking.
A precisely tuned 110 °C Ring-&-Ball softening point keeps the polymer solid during normal appliance self-heating, yet allows low-temperature application that protects heat-sensitive components such as SMD capacitors and thin-wall plastics. Once set, the adhesive forms a continuous water-blocking film that achieves dust-sealing on enclosure seams, cord entries and potting-free PCB edges, cutting the need for silicone gaskets or two-part epoxies. Hydrogenated tackifying resins remove unsaturated double bonds, yielding VOC emissions below 50 µg g⁻¹ (EU ISO 16000-6) and odor levels undetectable at 50 mm distance, helping production lines meet LEED, WELL and BSCI indoor-air standards.
The formulation is 100 % free of halogens, antimony, heavy metals, phthalates and formaldehyde, complying with RoHS 2.0, REACH SVHC 240. Resistivity tests show 3.8 × 10¹⁵ Ω cm volume resistivity and 520 V/mil dielectric strength, making the cured adhesive safe around 230 V circuits and LED solder points. This hot-melt stick tacks parts fast, seals against moisture and dust, survives appliance operating temperatures and keeps the work floor green, Electronic Hot Melt Glue Stick offers a ready-to-use, cost-saving solution that passes every compliance audit.
Product Specification Information
|
MODEL NUMBER |
TH-703 |
BRAND |
Tianze |
|
FORM |
Stick |
SIZE |
11.2*300mm |
|
COLOR |
White |
MAIN INGREDIENTS |
EVA |
|
SOFTENING POINT |
105-115℃ |
VISCOSITY @170℃ |
High |
|
OPEN TIME |
Medium |
SETTING TIME |
Fast |
|
PACKING |
20kg/box |
SAMPLE |
Free sample available |
